iPECS UCP - 2.44 ICLID Call Routing

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
126
Table 3.3.6.15-1 FUNCTION OUTPUT TYPE (PGM 175)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
5
CALL INFO (1-7)
SERIAL1 (1)
Defines the serial port or TCP
channel used to receive Call
Information output.
1 ~ 7 SERIAL1
6
ON-LINE SMDR (1-7)
SERIAL1 (1)
Defines the serial port or TCP
channel used for the On-line
SMDR.
1 ~ 7 SERIAL1
7
TRACE (1-7)
SERIAL1 (1)
Defines the serial port or TCP
channel used for the Trace output.
1 ~ 7 SERIAL1
8
DEBUG (1-7)
SERIAL1 (1)
Defines the serial port or TCP
channel used for the Debug output.
1 ~ 7 SERIAL1
9
ACD PACK (1-7)
SERIAL 1 (1)
Defines the serial port or TCP
channel used for the Unified
Messages.
1 ~ 7 SERIAL1
Table 3.3.6.15-2 OUTPUT FUNCTION TCP PORT (PGM 175)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
OFF-LINE SMDR (1-9999)
TCP PORT(NULL)
Defines the TCP port used for Off-
line SMDR/ Statistics output.
1 ~ 9999 NULL
2
ADMIN DATA (1-9999)
TCP PORT(NULL)
Defines the TCP port used for the
ADMIN Report output.
1 ~ 9999 NULL
3
TRAFFIC (1-9999)
TCP PORT(NULL)
Defines the TCP port used for the
TRAFFIC report output.
1 ~ 9999 NULL
4
SMDI (1-9999)
TCP PORT(NULL)
Defines the TCP port used for the
SMDI output.
1 ~ 9999 NULL
5
CALL INFO (1-9999)
TCP PORT(NULL)
Defines the TCP port used to
receive Call Information output.
1 ~ 9999 NULL
6
ON-LINE SMDR (1-9999)
TCP PORT(NULL)
Defines the TCP port used for the
On-line SMDR.
1 ~ 9999 NULL
7
TRACE (1-9999)
TCP PORT(NULL)
Defines the TCP port used for the
Trace output.
1 ~ 9999 NULL
8
DEBUG (1-9999)
TCP PORT(NULL)
Defines the TCP port used for the
Debug output.
1 ~ 9999 NULL
9
ACD PACK (1-9999)
TCP PORT(NULL)
Defines the TCP port used for
Unified Messages.
1 ~ 9999 NULL
10
I-SMDR (1-9999)
TCP PORT(NULL)
Defines the TCP port used for I-
SMDR(Interactive-SMDR)
1 ~ 9999 NULL
