Use the dial-pad to enter the desired button TYPE (1~6) and
value, if required. Refer to Table 3.3.3.4-1 for types and
value range. Defaults for the iPECS IP and LDP Phones are
shown in Table 3.3.3.4-2, for DSS Console defaults refer to
Table 3.3.3.4-3. In addition, for the DSS Console, use [VOL
UP]/[VOL DOWN] buttons to access the next/previous 24
flex buttons.
Press the [Save] button to store the Flex button data entry.
Table 3.3.3.4-1 FLEX BUTTON TYPE & VALUE CODES (PGM 115)
TYPE DESCRIPTION Remarks
1
Empty Button
Empty (unassigned) button, may be defined by the user.
2 User Program Fixed Numbering Plan
Assigns button to perform a User Program function from the Fixed
Numbering Plan, Appendix A.
3
{[SPEED] XXX}
Station or System Speed Dial bin.
4 Flexible Numbering Plan Code
Assigns button to dial a code from the Flexible Numbering Plan,
see Appendix B.
5
Station or Network Station
Assign network station number from network table.
6
MSN
Enter desired MSN Table index.
7
U-LOOP
U-Loop button for call wait of internal & external call
Table 3.3.3.4-2 iPECS IP & LDP PHONE BUTTON DEFAULT CONFIGURATION (PGM 115)
BTN
iPECS LDP Phone
9030 9008 7004 7008 7016 7024
1 {CO 1} {CO 1} Trans/
PGM*
DND {CO 1} {CO 1}
2
{CO 2}
{CO 2}
Speed*
Call Back
{CO 2}
{CO 2}
3
{CO 3}
{CO 3}
{LOOP}
{LOOP}
{CO 3}
{CO 3}
4
{CO 4}
{CO 4}
{LOOP}
{LOOP}
{CO 4}
{CO 4}
5
{CO 5}
{CO 5}
empty
{CO 5}
{CO 5}
6
{CO 6}
{CO 6}
empty
{CO 6}
{CO 6}
7
{CO 7}
{CO 7}
empty
{CO 7}
{CO 7}
8
{CO 8}
{LOOP}
empty
{CO 8}
{CO 8}
9
{CO 9}
empty
{CO 9}
{CO 9}
10
{CO 10}
empty
{CO 10}
{CO 10}
11
{LOOP}
{LOOP}
{LOOP}
12
{LOOP}
{LOOP}
{LOOP}
13
empty
empty
empty
14
empty
empty
empty
15
empty
empty
empty
16
empty
empty
empty
17
empty
empty
18
empty
empty
19
empty
empty
20
empty
empty
