iPECS UCP - Flexible DID Conversion Table

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
497
4.4.9.12 Flexible DID Conversion Table - PGM 231
Selecting Flexible DID Conversion Table will display the Flexible DID Table data entry page. For
convenience, the copy, paste, and drag is available to enter or modify data. Click [Save] button
after changing Value. Click [Initialize All table Data] to initialize all table and Click [Delete All
Table Data] to delete.
Figure 4.4.9.12-1 Flexible DID Conversion Table
When the received DID digits are converted, the resulting three-digit number may be used as an
index to the Flexible DID Conversion Table. The Flexible DID Table index is used when DID Line
is assigned a Conversion type 2, refer to the DID Service attributes section 4.4.4.6. Using the
index from the digit conversion a destination for the DID call is determined by a Look-up in the
Flexible DID Table. The destination for the call is generally defined as a type and a value. The
type selects options such as station, station group, VSF, etc. The value specifies the particular
station, station group, etc. In addition, ICLID routing can be enabled for DID lines or can be
assigned as an index to the Auto Ring Mode table.
Table 4.4.9.12-1 FLEXIBLE DID CONVERSION
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Day Ring Mode Destination
Destination setting for Day Ring mode.
N/A,
Station,
Station Group,
System Speed,
PABX transfer with
system speed,
VSF announcement,
VSF announcement
and Disconnect,
Networking,
Conference room,
Internal page,
External page,
N/A
Night Ring Mode Destination
Destination setting for Night Ring mode.
N/A
Timed Ring Mode Destination
Destination setting for Timed Ring mode.
N/A
Reroute Destination Destination setting for Reroute Ring mode. N/A
