3.3.8.3 MSN Table – PGM 202
When an ISDN Line assigned for DID operation, receives an incoming call, the call will be routed
to a station based on the Flexible DID Table Index in the MSN Table.
PROCEDURE:
MSN TABLE ATT
ENTER BIN NO ( 001 – 500 )
1. Press the [PGM] button and dial 202 and enter the bin
number (Ex.121). (eMG80:001~500/ eMG800:1~1500)
MSN TABLE 121
PRESS FLEX KEY ( 1 – 3 )
Use the dial pad to enter a MSN Table index number.
Press the Flex button for the desired MSN Table entry; refer
to Table 3.3.8.3-1.
Use the dial pad to enter the desired Table data.
Press the
[Save]
button to store the Table data entry.
Table 3.3.8.3-1 MSN ATTRIBUTES (PGM 202)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
MSN TABLE 121 CO RANGE
… - …
CO Line number associated with
the MSN.
None
2
MSN TABLE 121
INDEX : NOT ASSIGNED
Index to the Flexible DID Table,
PGM 231.
000~999 None
3
TABLE 121 TEL NUMBER
……………………..
Telephone Number (called number) 23 Digits None
