iPECS UCP - Flexible Button Default Table

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
508
4.4.9.20 Flexible Button Default Table – PGM 239
Selecting Flexible button default table will display the below page. Use the check mark to indicate
which attributes to modify; data for checked attributes is stored by clicking [Save] button.
Figure 4.4.9.20-1 Flexible Button Default Table
The system provide 30 default flexible button table so administrator can be configured each table
for using ‘Preset Flexible Button Default (240)’.
Administrator can assign the type among the below types on Flexible button.
Table 4.4.9.20-1 FLEX BUTTON TYPE
TYPE REMARK
N/A Empty (unassigned), may be defined by the user.
CO Line Assigns button to access a defined CO/IP line.
CO Group Assigns button to access a free line in the CO/IP Group.
Loop Assigns button to access a loop line.
Station Number
Assigns button as DSS/BLF for the assigned station number.
Programming
(Numbering Plan)
Assigns button to dial a code from the Flexible Numbering Plan, see Appendix section.
Programming (PGM)
Assigns button to perform a User Program function from the Fixed Numbering Plan,
Appendix section.
Station Speed Bin
Station Speed Dial bin.
System Speed Bin
System Speed Dial bin.
Net Station Number
Refer to section Network Numbering Plan Table - PGM 324.
U-Loop
U-Loop button for call wait of internal & external call.
