Table 3.3.4.1-1 H.323 VOIP ATTRIBUTES (PGM 130)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
5
RAS USAGE
(1:ON/0:OFF) : OFF
Determine whether VOIU/VOIB
Board will be used as a
Gatekeeper.
0: OFF
1: ON
OFF
6
RAS MULTICAST IP
224.0.1.41
Multi-cast IP address for RAS
Information of Gatekeeper.
IP Address 224.0.1.41
7
RAS MULTICAST PORT
(00001-65535): 01718
Multi-cast IP Port for RAS
Information of Gatekeeper.
IP Port # 1718
8
RAS UNICAST IP
82.134.80.2
Uni-cast IP address for RAS
Information of Gatekeeper.
IP Address 82.134.80.2
9
RAS UNICAST PORT
(00001-65535): 01719
Uni-cast IP Port for RAS
Information of Gatekeeper.
IP Port # 1719
10
RAS KEEP_ALIVE TM
(001-999) : 120 (sec)
The time between exchange of
RAS Information between GK
and VOIB/VOIU.
001-999
(SEC)
120
11
RAS NUM PLAN PREFIX
9
The numbering plan for Calling
Number in RAS Setup.
Number
(24 digits)
9
12
RAS GATEWAY ID
ONLY POSSIBLE BY WEB ADM
The Gatekeeper ID (This can be
programmed only via WEB
Admin).
128 Character
13
RAS LIGHT RRQ
(1:ON/0:OFF) : OFF
The system can be assigned to
use the simple RRQ (Registration
Request) message (ON) or the
full RRQ message (OFF).
0: OFF
1: ON
OFF
14
TCP KEEP ALIVE
(1:ON/0:OFF) : ON
The system will send a polling
message every 75 seconds to
assure the status of the TCP
connection.
0: OFF
1: ON
ON
15
FAIL OVER USAGE
(1:ON/0:OFF) : OFF
The H.323 call will be failover to
another line (FAIL OVER USAG:
ON).
0: OFF
1: ON
OFF
16
FAIL OVER TIME(sec)
(03-10) : 05
The H.323 call will be failover.
The time will be set.
03-10
(Sec.)
5
17
FAIL OVER CO GRP
(01-21) : . .
If the H.323 call will be failover,
assign another CO group.
01-21
18
Q931 START PORT
(00001-65535) : 02048
IP-Binding H.323 signaling
option: Q.931 TCP Start Port in
case of outgoing call.
00001-65535 2048
19
Q931 END PORT
(00001-65535) : 02559
IP-Binding H.323 signaling
option: Q.931 TCP End port in
case of outgoing call.
00001-65535 2559
