Table 3.3.4.1-1 H.323 VOIP ATTRIBUTES (PGM 130)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
20
H245 START PORT
(00001-65535) : 02560
P-Binding H.323 signaling option:
H.245 TCP Start Port.
00001-65535 2560
21
H245 END PORT
(00001-65535) : 03071
IP-Binding H.323 signaling
option: H.245 TCP End Port.
00001-65535 3071
22
RAS START PORT
(00001-65535) : 02048
IP-Binding H.323 signaling
option: RAS UDP Start Port.
00001-65535 2048
23
RAS END PORT
(00001-65535) : 03071
IP-Binding H.323 signaling
option: RAS UDP End Port.
00001-65535 3071
24
001 H323 VOIP ATTR (2ND)
PRESS FLEX KEY (1-4)
24-1
MEDIA START PORT
(00001-65535) : 06000
IP-Binding media option: Media
UDP Start Port.
00001-65535 6000
24-2
MEDIA END PORT
(00001-65535) : 07036
IP-Binding media option: Media
UDP End Port.
00001-65535 7036
24-3
DATA START PORT
(00001-65535) : 08500
IP-Binding option: Data Sharing
TCP Start Port.
00001-65535 8500
24-4
DATA END PORT
(00001-65535) : 08548
IP-Binding option: Data Sharing
TCP End Port.
00001-65535 8548
24-5
H.245 SETUP
(1:ON/0:OFF) : OFF
This feature is the ability of two
user endpoints to communicate
before call is actually established
in normal call mode. This feature
is not used when 'H323 Setup
Mode' is 'Fast'.
* Setup: Caller party tries to open
early media on receiving the
Setup message.
* Proceeding: Calling party tries
to open early media on receiving
the Proceeding message.
* Alerting: Calling party tries to
open early
media on receiving the
Alerting message.
0: OFF
1: ON
OFF
24-6
H.245 PROCEEDING
(1:ON/0:OFF) : OFF
0: OFF
1: ON
OFF
24-7
H.245 ALERTING
(1:ON/0:OFF) : OFF
0: OFF
1: ON
OFF
