iPECS UCP - Page 163

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
148
Table 3.3.7.2-1 STATION GROUP ATTRIBUTES — CIRCULAR & TERMINAL GROUPS
(PGM 191)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
3
CIRC 401 ANNC1 LOC
VSF ANNC .. (01 – 70)
The Station Group can be assigned
an announcement, which is played
if the call remains queued beyond
the ANNC 1 TMR duration. The
announcement location is the VSF
ANNC1 number. An entry of 00
indicates no announcement.
Including ‘#’ at the end of an entry
instructs the system to disconnect
after the announcement.
01~70 00: none
4
CIRC 401 ANNC2 LOC
VSF ANNC .. (01 – 70)
The Station Hunt Group can be
assigned a 2
nd
announcement,
which is played if the call remains
queued beyond the ANNC 2 TMR
duration. The announcement
location is the VSF ANNC2
number. An entry of 00 indicates no
announcement. Including ‘#’ at the
end of an entry instructs the system
to disconnect after the
announcement.
01~70 00: none
5
CIRC 401 ANNC2 RPT TMR
(000 - 999) : 000.
The 2
nd
announcement can be
repeated to calls that remain in
queue at intervals of the
Announcement 2 Repeat Timer.
NOTE
Repeating must be “ON” under
button 6 below.
000~999
(seconds)
000
6
CIRC 401 ANNC 2 RPT
(1: ON / 0: OFF): OFF
After the 2
nd
announcement, if the
call remains queued to the group,
the 2
nd
VSF announcement can be
repeated at the Announcement
Repeat Timer interval.
0: OFF
1: ON
OFF
7
CIRC 401 OVERFLOW DEST
S/H/V/SPD (Dial 1-4)
A call to the group will continue to
route through the group until
answered or all group members
have been tried. The call will
remain at the last station or will
pass to the assigned Overflow
Destination.
1-4
(1:Station
2:Station group
3:VSF Announce
4:System speed)
8
CIRC 401 OVERFLOW TMR
(000 - 600) : 180
A call to a group will remain at the
last station in the group or can be
sent to the assigned Overflow
Destination after expiration of the
OVERFLOW Timer.
000~600
(seconds)
180
