iPECS UCP - 5.6 Call Profile Routing

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
335
Table 4.4.4.11-1 CID/CPN ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
the caller id. For “Using Station’s COLP Attribute”, the
Station CLI type entered below will be used in place of the
station number.
CLIP Table Index
When a call is placed on an ISDN Line, the system will
send caller id using the number from the CLIP/COLP Table
entry defined by this parameter. The station number is
included as a suffix of the caller id. For “Using Station’s
CLIP Attribute”, the Station CLI Type entered below will be
used in place of the station number.
N/A
0-49
Station CLI
Station CLI
Type of Number for
Calling Party Info
For outgoing calls on an ISDN Line, this parameter defines
the “Type of Number Plan” provided in Calling Party
Information Element of the ISDN call SETUP message.
Unknown/
International/
National/
Unused/
Subscriber
National
Incoming Prefix Code
Insertion
Regional ISDN providers may use the Local Area Prefix
code for special services. In cases where the code is not
provided in the incoming call SETUP message, the system
can insert the My Local Prefix and My Area Code below in
SMDR, LNR, displays, etc.
OFF
ON
OFF
Outgoing Prefix Code
Insertion
Regional ISDN providers may use the Local Area Prefix
code for special services. The system can insert the “My
Area Code” and “My Local Prefix Code” in the Connect
message as defined in those items below.
OFF
ON
ON
International Access
Code
When an incoming call includes the international Country
code in the ISDN call SETUP message, the Country code
can be included in the station display. To include the
Country code, Incoming Prefix insertion, and CLI display in
Station Data must be ON.
Max. 4 digits -
My Area Code
Regional ISDN providers may use the Local Prefix and
Area codes for special services. The system will insert this
Local Area Code in the call SETUP messages defined
under the Incoming/Outgoing Prefix Code Insertion entries
above.
Max. 6 digits -
My Area Prefix Code
Regional ISDN providers may use the Local Prefix and
Area codes for special services. The system will use this
code for insertion of the Local Prefix Code in the call
SETUP messages if Local Prefix Insertion is enabled
above.
Max. 4 digits -
CLI Transit
When the system must send CLI to the ISDN for an off-net
call, the CLI can be either the original caller’s CLI or the
CLI of the Off-net forwarding/transferring station.
ORI/
CFW
CFW
ISDN Redirecting
Number
When the system needs to send a Redirecting number to
the ISDN for an off-net call, the Redirecting number can be
either the original caller’s CLI or the CLI of the Off-net
forwarding/transferring station. If it is no service then
system will not send this information. If it is configured for
OGR CLI (original CLI) then system will send original CLI
that is received from incoming CO line. If it is CFW CLI
then system will send the redirecting CLI that is the CLI of
the off-net call forwarding station.
NO SERVICE/
ORG CLI/
CFW CLI
NO
SERVICE
