Table 3.3.9.1.2-1 LCR LEADING DIGITS (PGM 221)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
LDT 01/000 : LCR TYPE
LCR MODE : BOTH (3)
This entry defines the LCR modes that
will apply to this Leading Digit Table bin.
To apply the DMT index, the LCR Type
must be part of the LCR Mode defined
in PGM 220.
1: Internal
2: CO Line
3: Both
Both
2
LDT 01/000 : LCR CODE
. . . . . . . . . . . .
Up to 12 digits that, if matched by the
user dialed digits, will access the DMT
entry for the index assigned for the Day
and Time zone below.
12 digits
0 ~ 9 and
‘*’ as a
wildcard
3
LDT 01/000 : DAY 1 DMT
INDEX(6DGT): . . . . . .
This entry defines the Digit Modification
Table index (00~99) for each Time
Zone for Day Zone 1. The appropriate
index will be selected for the current
Day and Time Zone. An entry of 6 digits
(2 per Time Zone) must be entered.
00~99
3 DMT
indices
4
LDT 01/000: DAY 2 DMT
INDEX(6DGT): . . . . . .
This entry defines the Digit Modification
Table index (00~99) for each Time
Zone for Day Zone 2. The appropriate
index will be selected for the current
Day and Time Zone. An entry of 6 digits
(2 per Time Zone) must be entered.
00~99
3 DMT
indices
5
LDT 01/000: DAY 3 DMT
INDEX(6DGT): . . . . . .
This entry defines the Digit Modification
Table index (00~99) for each Time
Zone for Day Zone 3. The appropriate
index will be selected for the current
Day and Time Zone. An entry of 6 digits
(2 per Time Zone) must be entered.
00~99
3 DMT
indices
6
LDT 01/000: CHK PASSWORD
(1:ON / 0:OFF) : OFF
If enabled (ON), when the dialed digits
match the LDT table digits, the system
will send second dial tone to request the
user input a valid Authorization code.
0: OFF
1: ON
OFF
7
LDT 01/000: ZONE NO
(001-100) : 001
If the LDT Zone Number of a station/co
line is equal to this value, this LDT table
is available to the station/co line.
001-100 001
