iPECS UCP - 4.12.2 SIP Trunk Service

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
310
Table 4.4.3.1-1 H.323 VOIP ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Call Setup No
Response Time
When Failover is enabled, the system places
the fail-over call if this timer expires before the
system receives a response to setup
messages.
0, 3-10 Sec. 5
Failover CO Group
Number
The system will place the Fail-over call
employing a CO/IP line from the assigned
CO/IP Line Group.
eMG80:1-21
eMG800:1~201
UCP:1~201
VOIP(VOIU) GW Port Usage
Q.931 Port Range
IP-Binding H.323 signaling option: Q.931 TCP
Port Range.
TCP port 2048-2559
H.245 Port
Range IP-Binding H.323 signaling option:
H.245 TCP Port Range.
TCP port 2560-3071
RAS Port Range
IP-Binding H.323 signaling option: RAS UDP
Port Range.
UDP port 2048-3071
Media Port Range
IP-Binding media option: Media UDP Port
Range.
UDP port
eMG80:6000-7036
eMG800:6000-14400
UCP:6000-19972
Data Sharing Port
Range
IP-Binding option: Data Sharing TCP Port
Range.
TCP port 8500-8548
External CODEC Priority Configuration
External CODEC
Priority Configuration
The system supports five Codecs and, for
negotiating purposes, the priority of each can
be defined. Codecs not assigned a consecutive
priority are not available during negotiations
with the host.
None/
g.711-u/
g.711-a/
g.723.1/
g.729/
g.729-a
none
