iPECS UCP - 6.5 Attendant Recall

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
369
Table 4.4.5.10-1 LED INDICATION
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Feature Message Wait FEATURE message wait. 00-14
FLASH 30 IPM
(2)
DSS Out-of-service state DSS button a station is in out-of-service state. 00-14
FLASH OFF
(00)
On-demand Ring mode DND led of attendant station for ring mode. 00-14
FLASH 60 IPM
(3)
Night Ring mode
DND led of attendant station for ring mode.
00-14
FLASH Steady
Timed Ring mode DND led of attendant station for ring mode. 00-14
FLASH 240 IPM
(5)
Auto Ring mode DND led of attendant station for ring mode. 00-14
eMG: FLASH 480 IPM (8)
UCP: FLASH Off (00)
Page Hold Button HOLD LED for paging. 00-14
FLASH 60 IPM
(3)
DSS Station DND(off duty) DSS button station in Station DND. 00-14
FLASH 120 IPM
(10)
Message Wait (Call Back) Message wait. 00-14
eMG: FLASH 30 IPM (2)
UCP: FLASH Off (00)
DSS in use DSS button station is in use. 00-14
Steady On
(1)
Table 4.4.5.10-2 LED FLASH RATE TABLE
Flash Rate DESCRIPTION
1 Steady On
2 30 ipm flash (30% On)
3 60 ipm flash (30% On)
4 60 ipm double wink (30% On-Off-On-Off & 70% On)
5 240 ipm flash (30% On)
6 240 ipm flutter (30% On-Off-On-Off-On & 70% Off)
7 480 ipm flash (30% On)
8 480 ipm flutter (30% On-Off-On-Off-On & 70% Off)
9 15 ipm flash (30% On)
10 120 ipm flash (30% On)
11 120 ipm flutter (30% On-Off-On-Off-On & 70% Off)
12 30 ipm double flash (30% On-Off-On & 70% Off)
13 480 ipm double wink (30% On-Off-On-Off & 70% On)
14 480 ipm double flash (30% On-Off-On & 70% Off)
