iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
469
Table 4.4.8.7-1 SIP PHONE ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
RELAY),
INFO(TELEPHONE
EVENT)
SMS Type
The Short Message Service Protocol (type) must be
selected to support SMS.
AUTO,
Text/plan,
Text/plan(KR),
Xnipm+xml
AUTO
CO DIAL TONE
When the user of a SIP phone dials a CO/IP Line
access code with Enblock dialing, the system can
provide virtual dial tone to the user.
OFF
ON
OFF
MWI NOTIFY
For compatible SIP phones, the system supports SIP
Subscribe/Notify. When enabled here, the system
sends Message Waiting notifications to the SIP phone.
OFF
message-summary
OFF
Request URI Type
The SIP Request header Domain field can use the SIP
phone’s IP address and port (Normal) or for ‘KT-FMC’
the Request URI Domain field will be system IP and
port.
Normal
KT FMC
Normal
Busy Service
To indicate a busy condition to the SIP phone, the
system can provide RTP packets with busy tone or the
SIP 486 Busy message. Providing busy tone requires a
VoIP DSP channel in the system.
System Busy Tone,
486 Busy Message
System Busy
Tone
Call Initiation Mode
The system can route calls to the SIP phone while busy
(Multiple). In this case, the SIP phone determines if Call
Waiting is supported. Otherwise, if the SIP phone is
busy, the system routes calls based on the busy
treatment (Single).
Multiple,
Single
Multiple
Pre Audio Connection
For DTMF
The system normally provides the 183 Session
Progress SIP message to establish a “Pre-audio”
connection. The “Pre-audio” connection permits the
system to send tones (CO dial tone or ringback tone) to
the SIP phone. In addition, the SIP phone can send
DTMF tones the user dials in response to CO dial tone
or a remote IVR message. Some SIP phones may
require the 200 OK message, which “answers” the call,
to allow dialing after the call has been initiated.
183 Session
Progress,
200 OK
183 Session
Progress
Do Not Overwrite
Station Name
This feature can be set in case of the following Range:
- OFF(REG): Extension name will be updated with
displayed in REGISTER message.
- ON: Extension name will not be updated.
- OFF(INV): Extension name will be updated with
displayed in INVITE message.
- OFF(REG+INV): Extension name will be updated
with displayed in REGISTER or INVITE message.
OFF(REG),
ON,
OFF(INV),
OFF(REG+INV)
OFF(REG)
Follow CO Enblock
Process
Skip "dial tone by system" phase and deliver
transparent message of CO trunk to SIP phone.
OFF
ON
OFF
Suffix DID Tbl to CLI
If this option is ON, CLI is published by suffixing DID
Conversion table index.
OFF
ON
OFF
SIP Profile
Select the SIP Profile type between Default and
CISCO-CP.
- Default: Normal SIP phone.
- CISCO-CP: CISCO SIP phone.
Default,
CISCO-CP
Default
