iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
545
Table 4.4.13.8-1 INTER-ZONE ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Dest. RTP
Relay Device
Slot Seq.
The Sequence number associated with the VoIP channels to
handle packet relay for the Destination Zone is defined. When
Utilization is Separate the channels are used for devices in the
destination Zone, otherwise they are used as back up for both
Sequence
Number
Max Inter Zone
connection
This field determines the maximum Inter Zone connections
between the source zone and destination zone. When this value is
set to 0, there is no limit on the number of connections between
eMG80:0-140
eMG800: 0-1200
UCP:0-2400
0
Use Firewall IP
If this option is set to ON, System use Firewall IP of VoIP board
for RTP relay between Zones. But, if this option is OFF, System
use Local IP of VoIP board for RTP relay between zones.
OFF
ON
ON
