iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
553
Table 4.4.15.1-1 Common attributes
ATTRIBUTE DESCRIPTION RANGE DEFAULT
UCS Server Type
The server that provides UCS service can be iPECS
system (Standard) or the external UCS Server
(Premium). Additional video and collaboration features
are provided by the UCS Server as Premium service.
When the UCS Server is employed, the Standard Client
Login information (PGM 446) is transferred from iPECS
system to the UCS Server after the client is registered.
If "Preserve UCS DB when server type is changed" is
checked, UCS DB will not be initialized when UCS
server mode is changed.
Standard
Premium
Standard
LDAP Server Settings
Server Display
Name
When the UCS Client requires access to an LDAP
server, the system will provide the LDAP server
information to the client. The server name is defined in
this field.
15 characters
Server IP
When an LDAP server is employed, the IP address of
the server must be defined.
0.0.0.0
Server Port
When an LDAP server is employed, the TCP/IP port of
the server must be defined.
00001-65535
Require Login
The UCS Client ID and Password may be required for
log in to the LDAP server.
OFF
ON
ON
Use SSL
When supported by the server, the client can employ
SSL (Secure Sockets Layer) for added security.
OFF
ON
OFF
Search Base
Search base means Search option. You can get the
search option from LDAP Server manager. For
example, if OU (Organization Unit) is OC and DC
(Directory Company) are ucapp and com, you can give
the option "OU=OC, DC=ucapp, DC=com" in this field.
You will get the desired directory.
