Table 3.3.6.10-1 BUTTON LED FLASH RATE (PGM 170)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
11
COL SUPP CW
FLASH 240 IPM FLUTTER
CO button supplementary call
waiting flashing rate.
00-14 FLASH
240 IPM
FLUTTER(6)
12
COL SUPP HOLD
FLASH 480 IPM
CO button supplementary hold
flashing rate.
00-14 FLASH
480 IPM(7)
13
DSS CO RING
FLASH 30 IPM
DSS button CO ring flashing rate. 00-14 FLASH 30
IPM (2)
14
DSS ALL RING
FLASH 60 IPM
DSS button ICM ALL ring flashing
rate.
00-14 FLASH 60
IPM (3)
15
DSS ASC RING
FLASH 120 IPM
DSS button ICM ring associate
device flashing rate.
00-14 FLASH
120 IPM(10)
16
DSS IN DND
FLASH 60 IPM
DSS button station in DND. 00-14 FLASH 60
IPM (3)
17
DSS LOCK OUT
FLASH 480 IPM FLUTTER
DSS button station in lockout. 00-14 FLASH
480 IPM
FLUTTER(8)
18
DSS PRESEL MSG
FLASH 30 IPM
DSS button station in pre-selected
message.
00-14 FLASH 30
IPM (2)
19
DSS ICM HOLD
FLASH 60 IPM
DSS button station on ICM hold. 00-14 FLASH 60
IPM (3)
20
DSS OTHER
FLASH 120 IPM
DSS button station in other state. 00-14 FLASH
120 IPM(10)
21
UCD QUE RING 2
FLASH 60 IPM
CIQ Threshold # 1. 00-14 FLASH 60
IPM (3)
22
UCD QUE RING 6
FLASH 120 IPM
CIQ Threshold # 2. 00-14 FLASH
120 IPM(10)
23
UCD QUE RING 7-X
FLASH 240 IPM
CIQ Threshold # 3. 00-14 FLASH
240 IPM(5)
24
UCD DND(OFF DUTY)
FLASH 120 IPM
UCD agent is off duty (UCD DND). 00-14 FLASH
120 IPM(10)
25
UCD WARNING
FLASH 120 IPM
UCD warning tone. 00-14 FLASH
120 IPM(10)
26
UCD HELP
FLASH 120 IPM
UCD help request/response. 00-14 FLASH
120 IPM(10)
