Table 3.3.6.10-1 BUTTON LED FLASH RATE (PGM 170)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
27
FEATURE RECORD
FLASH 240 IPM
FEATURE voice record button. 00-14 FLASH
240 IPM(5)
28
FEATURE MSG WAIT
FLASH 30 IPM
FEATURE message wait. 00-14 FLASH 30
IPM (2)
29
DSS OUT OF SERVICE
FLASH OFF
Station in out-of-service state. 00-14 FLASH
OFF (00)
30
ON DEMAND RING MODE
FLASH 60 IPM
DND LED of attendant for ring
mode indication (On-demand).
00-14 FLASH 60
IPM (3)
31
NIGHT RING MODE
FLASH STEADY
DND LED of attendant for ring
mode indication (Night).
00-14 FLASH
STEADY(01)
32
TIMED RING MODE
FLASH 240 IPM
DND LED of attendant for ring
mode indication (TIMED).
00-14 FLASH
240 IPM(5)
33
AUTO RING MODE
FLASH 480 IPM
DND LED of attendant for ring
mode indication (AUTO).
00-14 FLASH
480 IPM(7)
34
PAGE HOLD BUTTON
FLASH 60 IPM
HOLD LED for paging. 00-14 FLASH 60
IPM (3)
35
DSS OFF DUTY
FLASH 120 IPM
DSS button station in Hunt DND. 00-14 FLASH 120
IPM (10)
36
CALLBK
FLASH OFF
Message wait (call back). 00-14 FLASH OFF
Table 3.3.6.10-2 FLASH RATE TABLE (PGM 170)
Flash Rate DESCRIPTION
00
Flash OFF
01
Steady On
02
30 ipm flash (30% On)
03
60 ipm flash (30% On)
04
60 ipm double wink (30% On-Off-On-Off & 70% On)
05
240 ipm flash (30% On)
06
240 ipm flutter (30% On-Off-On-Off-On & 70% Off)
07
480 ipm flash (30% On)
08
480 ipm flutter (30% On-Off-On-Off-On & 70% Off)
09
15 ipm flash (30% On)
10
120 ipm flash (30% On)
11
120 ipm flutter (30% On-Off-On-Off-On & 70% Off)
12
30 ipm double flash (30% On-Off-On & 70% Off)
13
480 ipm double wink (30% On-Off-On-Off & 70% On)
14
480 ipm double flash (30% On-Off-On & 70% Off)
