iPECS UCP - 2.46.2 Integrated Auto Attendant

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
129
Table 3.3.6.17-1 SMDR ATTRIBUTES (PGM 177)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
15
MAIL SEND WEEKLY SET
N/A (0-7)
Sets day of week to send SMDR data
weekly (0 for no weekly data, 1-7 for
Monday through Sunday)
0-7 0
16
MAIL SEND DAILY SET
00(00-23)
Sets time-of-day for SMDR data to be
sent on a daily basis (00 for no daily
records, 01-23 for hour of the day).
00-23 00
17
AUTO SEND MODE
(1 : ON/ 0: OFF) : OFF
If the SMDR buffer is full, the system can
automatically send a notification by e-
mail.
0: OFF
1: ON
OFF
18
AUTO DELETE MODE
(1 : ON/ 0: OFF) : OFF
Delete SMDR records after sending e-
mail.
0: OFF
1: ON
OFF
19
LONG DISTANCE CODE
0 .. .. .. ..
For SMDR and COS purposes, five (5)
Long Distance codes of up to two (2)
digits each can be assigned. If dialed as
the 1
st
digits, the call is considered an LD
call.
Flex button
1~5 +
digits 0~9
& ‘*’ as a
wild card
BTN 1: 0
20
SMDR RIN/CLI/CPN SVC_I
(0:RIN/1:CLI/2:CPN):0
For incoming calls, the system will send
the defined data item for “Field I”. The
data item may be CLI, CPN or Ring
Service Time. Note the User dialed
number is always provided for an
outgoing call.
0: RING
1: CLI
2: CPN
RING time
21
MSN PRINT ON SMDR
(1:ON/0:OFF) : OFF
Print MSN number Information in SMDR
Record.
0: OFF
1: ON
OFF
22
SMDR RIN/CLI/CPN SVC_II
(0:RN/1:CL/2:CP/3:NO):2
For incoming calls, the system will send
the defined data item for “Field II”. The
data item may be CLI, CPN or Ring
Service Time.
0: RING
1: CLI
2: CPN
3: None
CPN
23
PRINT SERIAL NO
(1 : ON/0:OFF) : OFF
Print record number as part of SMDR
output, will reset to 1 when SMDR
capacity is reached or SMDR records
are deleted, see button 18.
0: OFF
1: ON
OFF
24
SMDR ATTRIBUTRS(2ND)
PRESS FELX KEY (01-19)
01-19
24-1
SMDR HIDE DGT
1:RIGHT/0:LEFT) : RIGHT
When “HIDDEN DIALED DIGIT” is
enabled, button 8 above, this field
determines if leading or trailing digits are
hidden.
0: Left
1: Right
Right
24-2
SMDR INTERFACE SVC
(0 : OFF/1:CO/2:CO&ICM) : 0
When enabled, the system stores SMDR
data to send to applications including
NMS upon request.
0: OFF
1: CO
2:CO&ICM
OFF
24-3
SMDR ICM SAVE
(1:ON/0:OFF) : OFF
When enabled, intercom call data is
stored as part of the SMDR data.
0: OFF
1: ON
OFF
