iPECS UCP - Page 165

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
150
Table 3.3.7.2-1 STATION GROUP ATTRIBUTES — CIRCULAR & TERMINAL GROUPS
(PGM 191)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
17
CIRC 401 FORCED DEST
S/H/V/SPD (DIAL 1-4)
When a call is delivered to the
group the system can redirect the
call to the Forced destination if
enabled under button 18 below.
1-4
(1:Station
2:Station group
3:VSF Announce
4:System speed)
-
18
FORCED FWD DEST USAGE
(1:ON/0:OFF): OFF
Enables the system to redirect
group calls to the Forced
destination defined under button 17
above.
0: OFF
1: ON
OFF
19
WAIT IF 1ST ANNC BUSY
(1:ON/0:OFF): ON
When a call assigned to receive an
announcement arrives and all
channels are busy, the call may
wait with Ring back until a channel
is available (ON) or bypass the
announcement.
0: OFF
1: ON
ON
20
GROUP NAME
……………………………….
A hunt group name can be
designated.
20 character ….
21
CIRC 401 MAX QUE C-CNT
(00-99) : 99
When the number of calls queued
to the group match this parameter,
new calls will receive error tone
and be disconnected after the VSF
AA announcement, if assigned, is
played.
00-99 99
Table 3.3.7.2-2 STATION GROUP ATTRIBUTES — UCD/ACD GROUPS (PGM 191)
BTN − ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
ACD 403 ANNC 1 TMR(1s)
(000 – 999) : 015
If all stations in the group are busy
when a call is offered, the call may
continue to wait (queue) for an
available station.
If the queue period exceeds this 1
st
Announcement Timer, the call may be
sent to a VSF announcement.
If the timer is set to 000, the call will
receive the first announcement, in full,
prior to the hunt process (guaranteed
announcement).
000~999
(seconds)
015
2
ACD 403 ANNC 2 TMR(1s)
(000 – 999) : 000
After the 1
st
announcement, a 2
nd
ANNC TMR is activated. At expiration,
if the call remains queued to the group,
the call is sent to the assigned 2
nd
VSF
announcement.
000~999
(seconds)
000
