Table 3.3.7.2-3 STATION GROUP ATTRIBUTES — RING GROUPS (PGM 191)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
7
RING 405 OVERFLOW DEST
S/H/V/SPD (Dial 1-4)
A call to the group rings at member
stations until the Overflow timer
expires then the call passes to the
assigned Overflow Destination.
1-4
(1:Station
2:Station group
3:VSF Announce
4:System speed)
8
RING 405 OVERFLOW TMR
(000 - 600) : 180
A call to a ring group will continue to
ring stations in the group or be sent
to the assigned Overflow
Destination after expiration of the
OVERFLOW Timer.
000~600
(seconds)
180
9
RING 405 WRAP-UP TMR
(000 - 999) : 002
After terminating any call, a Ring
Group member will be maintained in
a busy state for the duration of the
WRAP-UP Timer.
000~999
(seconds)
002
10
RING 405 MUSIC SRC
(00–10) : 01
A Music source is assigned so that
calls to the group will receive audio
from the assigned source in place of
ring-back tone.
00: Ring-back
01: Int music
02: Ext music
03: VSF MOH
04: SLTMOH1
05: SLTMOH2
06: SLTMOH3
07: SLTMOH4
08: SLTMOH5
09: VSFMOH2
10: VSFMOH3
01
11
RING 405 MAX QUE C-CNT
(00-99) : 99
When the number of calls queued is
reached, new calls will receive error
tone and be disconnected after the
VSF AA announcement, if assigned,
is played.
00-99 99
12
RING 405 MBR FORWARD
(1 : ON/ 0: OFF) : ON
A member activating Call Forward
may be placed in an unavailable
state for hunt group calls (ON).
When OFF, group calls are sent to
the member as normal.
0: OFF
1: ON
ON
13
MAILBOX MSG WAIT STA
. . . .
When a group calls overflows or
routes to the VM group, a station
number is used to identify the
Mailbox for the Ring group
messages.
Station ….
14
MAILBOX PASSWORD
…………
The password associated with a
group Mailbox is defined here. The
password is used in conjunction with
the Ring group as with a normal
station.
12 digits ….
15
RING 405 FORCED DEST
S/H/V/SPD (DIAL 1-4)
When a call is delivered to the group
the system can redirect the call to
the Forced destination if enabled
under button 16 below.
1-4
(1:Station
2:Station group
3:VSF Announce
4:System speed)
-
