iPECS UCP - 3.9 Intercom Transfer

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
278
Table 4.4.2.4-1 CLI Attributes
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Station CLI 5
message in place of the station number.
Type
CLI / Redirect Display
When an incoming call is Redirected in the carrier’s
network, the call SETUP message will contain an original
and redirected CLI. This selection determines if the
iPECS IP and LDP Phone will display the original or
redirected number.
Original CLI/
Redirect CLI
Original CLI
Station or Attendant
When the system sends a station number with CLIP or
COLP, the number can be either the Attendant number
or the number of the station.
Station
Attendant
Station
CPN Type
NOT SEND: CPN is not sent to S0 interface.
STATION NUMBER: Station number is sent as CPN to
S0 interface.
BYPASS FROM NET: Incoming CPN is sent as CPN to
S0 interface.
Not send,
Station number,
By pass from
NET
Not send
CLI Name Preference
NET: If CLI name is provided from network, then it is
displayed. If CLI name is not provided from network, the
matched Speed name is displayed.
SPD: If CLI is matched with Speed bin and it has name,
then the matched Speed name is displayed. If CLI is not
matched or matched Speed name is not configured, CLI
name from network is displayed.
NET,
SPD
NET
Display Restricted
Caller Number
When {Display Restricted Caller Number} in CLI
Attributes (113) of a station is ON, although the caller
number is restricted in ISDN message, the ringing station
displays the caller number.
OFF
ON
OFF
Display Full CLI
The system provides CLI information by displaying on
LCD. If this option is ON, the full CLI information is
displayed on the second line of LCD.
If this option is OFF, the CLI information is displayed
from the left to the center on the second line partially. It
means the CLI information is limited so that the full CLI
can’t be displayed.
OFF
ON
ON
