iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
344
Table 4.4.5.1-1 SYSTEM ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Unified Message
Format
System Integration Messages are sent out the defined
serial or TCP channel.
OFF
ON
OFF
Conference Room CO
Tel Number
ISDN DID number an external party must dial to enter
a Conference room.
Max. 15 digits
Record warning tone
When call recording is active, a tone can be sent to all
connected parties to indicate the conversation is
being recorded.
OFF
ON
ON
UCP (MPB) DIFF
SERVE
Diff-Serv Code Point applied to packets from LAN port
of the UCP (iPECS eMG LAN port of the MPB).
00-63 46
Device Upgrade Mode
Transfer mode for upgrades from MPB to an iPECS
device.
FTP
TFTP
FTP
CO Transfer Tone
When a CO call is transferred to a busy extension,
Ring Back Tone or Music On Hold will be played to
the CO Line.
MOH/
Ring-Back Tone
Ring-Back Tone
Conference Warning
Tone
When a new member joins a conference room, the
system provides warning tone to conference
members.
OFF
ON
ON
Dummy Dial Tone
When a CO line does not provide dial tone, the
system can provide dummy dial tone.
Unused/
Use
Unused
SIP Station Mode
SIP phones may set-up a point-to-point RTP
connection (PTP) or to assure a controlled
connection, RTP can be routed via a VoIP channel
(RTD).
RTD/
PTP
Routed
SMS Center Number
When the PSTN will be used to send SMS, the phone
number of the Short Message Service Center must be
entered.
Max. 23 digits
SMS Center CLI
When the CO/IP Line will be used to receive SMS, the
Caller Id expected from the Short MSG Service
Center must be defined.
Max. 23 digits
SMS Protocol
The Short Message Service Protocol must be
selected to support SMS.
None/
ETSI-P1/
ETSI-P2/
KT-LivingNet/
SIP-Text/
SIP-XML/
KT IP-PBX/
SKN IP-PBX/
KT XML
NONE
G.722 Packetization
The G.722 voice frame packetization time determines
the interval at which voice samples are packetized
and sent when the G.722 codec is used.
10/20/30
(1 msec)
020
Transit-out security
The system will check the IP address for transit-out
calls in the master system. If not valid the transit-out
call is denied.
Unused/
Use
Use
Emergency call
attendant Notify
The Attendant can be notified when another user in
the system dials emergency number.
Unused/
Use
Use
3-Way Conference
Preference
When 3-way conference calling, the system uses the
selected device to establish the conference mixing.
When “Local” is assigned, the device, such as a SIP
Local/
MCIM
Local
