iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
343
Table 4.4.5.1-1 SYSTEM ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Off-Hook Ring Type
Off-hook ring can be a single tone burst or muted
normal ring.
MUTE/
BURST
MUTE
Page Warning Tone
A warning tone can be sent prior to a page
announcement.
OFF
ON
ON
Automatic Privacy
Automatic Privacy can be disabled, allowing stations
to join an active CO/IP call. A warning tone can be
provided, see Privacy Warning Tone below.
OFF
ON
ON
Privacy Warning Tone
If desired, a warning tone can be provided when
privacy is overridden.
OFF
ON
ON
ACD Print Enable
ACD statistics can be periodically sent to the
assigned serial port. To provide periodic reports, this
feature must be ON.
OFF
ON
OFF
ACD Print Timer
This entry defines the time, in 10-second increments,
between the periodic ACD reports assigned above.
001~255
(1 sec)
010
Clear ACD Database
When a periodic report is sent, the ACD database can
be cleared automatically, if “ON”.
OFF
ON
OFF
Override 1st CO Group
When a user dials ‘9’, the system can search all
CO/IP Groups for the first available CO/IP line.
OFF
ON
ON
Codec Type
The default codec can be defined as G.711, G.729,
G.722 or G.723.1 for decreased bandwidth needs.
The selected codec will be used on all internal
communications as well as for remote iPECS devices.
G.729/
G723.1/
G711/
G722
G711
G.711 Packetization
The G.711 voice frame packetization time determines
the interval at which voice samples are packetized
and sent when the G.711 codec is used.
10/20/30
(1 msec)
020
G.723 Packetization
The G.723.1 voice frame packetization time
determines the interval at which voice samples are
packetized and sent when the G.723.1 codec is used.
30/60
(1 msec)
030
Network Time/Date
The system can use ISDN Network time or NTP to
synchronize time with the ISDN or data network.
ISDN sync is not available in USA version.
Disable/
ISDN/
NTP
Disable
Incoming Toll Check
The system can invoke COS dialing restrictions when
a user dials while connected to incoming call.
OFF
ON
ON
Web Server Port/TLS
for Web
This field determines the TCP port employed to
access the system WEB server. This field also
enables Transport Layer Security (TLS) for access to
Web Admin.
00001-65535/
Enable or Disable
80/
Disable
Auth Retry Count
When an Authorization code is required, the user may
attempt to enter a Valid code up to the maximum
value defined in this field.
1-9 3
Simple Auth Code
Usage
System Authorization codes are entered by the user
as “*” and the code (ON) or “*”+ the Auth code index
and the code (OFF).
OFF
ON
ON
COS 7 when Auth Fail
If a user fails to enter a valid Authorization code in the
number of attempts assigned in Auth Retry Count
above, the station is disconnected or the Station COS
is changed to COS 7. In the latter case, the user must
employ COS Restore in Station User PGM 2 to return
the station to the normal COS.
OFF
ON
OFF
