iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
444
Table 4.4.8.1-1 SIP Common Attributes
ATTRIBUTE DESCRIPTION RANGE DEFAULT
TLS Security
Change password that is used to encrypt TLS
certification periodically.
OFF
ON
OFF
SRTP Security Allow only SRTP call (blocking none SRTP call).
OFF
ON
OFF
SIP Message blocking option
IP AUTH USAGE
ON: Discard SIP Request (INVITE
, REGISTER, NOTIFY,
OPTIONS, MESSAGE …) if VIA IP and From IP are
neither the server IP nor SIP Extension IP.
OFF
ON
ON
Remote Register
ALLOW: proceed REGISTER from remote site.
DENY: Discard all remote REGISTER.
(It is applied with IP AUTH USAGE ON)
ALLOW/
DENY
ALLOW
REGISTER Check
Time
Time interval to check invalid remote REGISTER
flooding. (It is applied with IP AUTH USAGE ON and
Remote REGISTER ALLOW)
0~3600
(Sec.)
0
REGISTER
Threshold
Threshold value to decide if it is invalid remote
REGISTER flooding. (It is applied with IP AUTH USAGE
ON and Remote REGISTER ALLOW)
0~60000 0
REGISTER Lock
Time
Time interval to discard remote REGISTER if it is
REGISTER flooding state. (It is applied with IP AUTH
USAGE ON and Remote REGISTER ALLOW)
0~250
(Min.)
0
SIP SMS Option
SMS Domain Domain Name used for sending SIP SMS Max. 32 characters
SMS request URI
Request URI for sending SIP SMS.
This is only for Korea telecom.
Max. 32 characters 1549
SMS Mode
Assign SMS mode(normal or external)
This is only for Korea telecom.
Normal,
External
Normal
SIP FAX Option
Start w/ G.711
Fax
G711 Fax path through Mode. G711 will be negotiated
as voice path and Fax will send this voice path.
OFF
ON
OFF
G.711 Fax
method
G711 Fax Mode. VBD – VBD codec attribute will be
added in SDP.
711A/711U/711A(VBD)
.711U(VBD)
711A
T38 FAX
Failover(711)
When T38 Negotiation is failed, G711 Codec will be used
for Fax Transmission.
OFF
ON
OFF
Miscellaneous Option
OCS Prefix Code
When the server type assigned for a SIP Trunk is OCS,
the system will send these digits as a prefix to the
number in the SIP “To:” header.
Max. 8 Digits
SIP Pound Use
SIP employs Enblock dialing where the user dials all
digits before they are sent to the carrier for processing.
When the user completes dialing of a SIP call, ‘#’ is used
to indicate end of dialing. If users must be able to dial ‘#’,
SIP Pound Use can be disabled and the system will
automatically send digits at expiration of the inter-digit
time.
OFF
ON
OFF
BLF SYNC
NOTIFY Timer
When the system reboots, the button LEDs of SIP
phones may indicate erroneous status. To display proper
status LEDs, the system sends a Notify message to
10-360 10
