iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
449
Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
announcement to play and user dialed digits to be
analyzed by CCR and, if the CCR destination is an
external number, the system can send a SIP 3xx
call diversion message to forward the call via the
SIP network.
RTP Diversion Method Reserved Currently.
Recursing /
Non-Recursing
Recursing
OPTIONS Usage (Keep
Alive)
With “OPTIONS Usage” ON, an Option message is
sent at intervals of the Check Message Send Timer
assigned in PGM 210 to assure a connection with
the SIP CO. SIP COs generally provide an Option
message. In this case, the UCP should not be
enabled here.
OFF
ON
OFF
Proxy Registration Timer
Periodically, the system must re-register with the
SIP Registrar. While this timing is often negotiated
with the Registrar, the system can be configured
with this timer to establish the re-register interval.
1-65535 3600
Proxy Server UDP Port
When employing UDP transport, this port number is
employed for messages to the SIP proxy.
Port 5060
Proxy Server TCP Port
When employing TCP transport, this port number is
employed for messages to the SIP proxy.
Port 5060
Proxy Server TLS Port
When employing TLS transport, this port number is
employed for messages to the SIP proxy.
Port 5061
Registration UID Range
The User Id indices from the SIP User ID Attributes
Table PGM 126 that will register with the SIP
Service Provider’s SIP Registrar must be
configured.
Max. 140 Entries
DTMF Type
DTMF dialing signals can be sent from the system
using in-band or various Info messages. The
method or type must match the SIP Call Server.
INBAND/
2833/
INFO (DTMF)/
INFO (DTMF
RELAY)/
INFO(TELEPHON
E EVENT)/
INFO(NORTEL
NETWORKS)
INBAND
Action with REG Failure
When registration fails, the link is down to the SIP
Call server, or the system receives no response to
an Invite message in the “Call Setup No-response”
timer below, the call will return error tone (Wait
Idle), or Fail-over to a Line from the Fail-over CO
Group specified below (Idle).
IDLE/
WATI IDLE
IDLE
Media Port
The UDP ports used for RTP (media) packets can
be limited to a fixed range.
UDP Port
eMG80:6000-
7036
eMG800:6000-
14400
UCP:6000-
19972
