iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
450
Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Secondary Proxy Server
It is used for SIP proxy server redundancy.
IP Address
Secondary Domain
It is used for SIP proxy server redundancy.
Max. 32
Secondary Proxy Server
It is used for SIP proxy server redundancy.
Port
ID Presentation Option
ID Usage
P-Asserted-ID
The system normally provides a P-Asserted ID in
SIP messages. The system can be configured not
Unused
Use
Use
Remote-Party-ID
The system normally provides a Remote-Party-ID in
SIP messages. The system can be configured not
Unused
Use
Use
Privacy(CLIR)
Presentation
SIP employs various headers that include a User Id
and Name. In some cases, it may desirable to
restrict the called party from receiving this
information. Several options for Caller Id restriction
can be applied.
Anonymous
Name &
Anonymous
Number/
Anonymous
Name/
Privacy: user/
Privacy: id/
Privacy:
user;id;critical/
Privacy: id &
anonymous & P-
Anonymous
Name &
Anonymous
Number
ID Individuality
CID Password
Enter CID Password.
From ID
The Id in the “From” header of SIP messages can
be based on the calling station, the User Id or a
fixed User Id.
Extension SIP User Id: one of three SIP User
Ids assigned to the station in PGM 111. Select
which of the three indices to use in the SIP UID
Selection below.
Extension outgoing CLI: the CLI configured for
the station through Web PGM 113 and 151.
Authorized Representative Id: the User Id of the
“Authorized Representative Id” assigned to the SIP
User Id that is indexed to the station in PGM 111.
The specific index is selected below as the SIP UID
Selection.
Fixed Table: the SIP User ID from the SIP UID
Fixed Table Index attribute assigned below.
Extension SIP-
User-ID Table/
Extension
outgoing-CLI/
Authorized
Representative
ID/
Fixed Table
Extension SIP-
User-ID Table
From Display
The “Display” field of the “From” header can be
configured to use the below:
SYS RULE/
SYS RULE
