iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
451
Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
System Rule:
a. From ID = Extension SIP User-ID Table,
display Contact Display Name from PGM 126,
otherwise display Station Name from PGM 111 or
blank.
b. From ID = Extension Outgoing CLI, display
Station Name from PGM 111 or blank.
c. From ID = Authorized Rep Id, display
Contact Display Name of Authorized Rep Id from
PGM 126 otherwise display Station Name from
PGM 111 or blank.
d. From ID = Fixed Table display Contact
Display Name from PGM 126 or Station Name from
PGM 111 or blank.
Extension outgoing CLI: the CLI configured for
the station through Web PGM 113 and 151
outgoing-CLI
P-Asserted-ID
The Id in the “P-Asserted Id” header of SIP
messages can be based on the calling station, the
User Id or a fixed User ID.
Ext SIP User ID: one of three SIP User Table
indices assigned to the station in PGM 111. Select
which of three in the SIP UID Selection below.
Extension outgoing CLI: the CLI configured for
the station through Web PGM 113 and 151.
Authorized Representative ID: the User Id of
the “Authorized Representative ID” assigned to the
SIP User Id that is indexed to the station in PGM
111. The specific index is selected below as the SIP
UID Selection.
Fixed Table: the SIP User ID from the SIP UID
Fixed Table Index attribute assigned below.
Extension SIP-
User-ID Table/
Extension
outgoing-CLI/
Authorized
Representative
ID/
Fixed Table
Extension SIP-
User-ID Table
P-Asserted-ID Display
The “Display” field of the “P-Asserted Id” header
can be configured to use the below:
System Rule:
a. P-Asserted ID = Extension SIP User-ID
Table, display Contact Display Name from PGM
126, otherwise display Station Name from PGM 111
or blank
b. P-Asserted ID = Extension Outgoing CLI,
display Station Name from PGM 11 or blank
c. P-Asserted ID = Authorized Rep Id, display
Contact Display Name of Authorized Rep Id from
PGM 126 otherwise display Station Name from
PGM 111 or blank
d. P-Asserted ID = Fixed Table display
Contact Display Name from PGM 126 or Station
Name from PGM 111 or blank
Extension outgoing CLI: the CLI configured for
the station through Web PGM 113 and 151.
SYS RULE/
Extension
outgoing-CLI
SYS RULE
