iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
452
Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Contact ID
The Id in the “Contact ID” header of SIP messages
can be based on the calling station, the User Id or a
fixed User ID.
Ext SIP User ID: one of three SIP User Table
indices assigned to the station in PGM 111. Select
which of three in the SIP UID Selection below.
Extension outgoing CLI: the CLI configured for
the station through Web PGM 113 and 151.
Fixed Table: the SIP User Id from the SIP UID
Fixed Table Index attribute assigned below
Extension SIP-
User-ID Table/
Extension
outgoing-CLI/
Fixed Table
Extension SIP-
User-ID Table
Remote-Party-ID
The Id in the “Remote-Party ID” header of SIP
messages can be based on the calling station, the
User Id or a fixed User Id.
Ext SIP User ID: one of three SIP User Table
indices assigned to the station in PGM 111. Select
which of three in the SIP UID Assignment section
below.
Extension outgoing CLI: the CLI configured for
the station through Web PGM 113 and 151.
Fixed Table: the SIP User ID from the SIP UID
Fixed Table Index attribute assigned below.
Extension SIP-
User-ID Table/
Extension
outgoing-CLI/
Fixed Table
Extension SIP-
User-ID Table
Offnet Call Route ID Transit
CO to Offnet Direct Call Route
The below applies to calls routed from a CO/IP Line to an Off-net location by the system over a SIP Trunk.
From/Contact ID
The ID in the “From” and “Contact” headers of SIP
messages employ System Attendant CLI, the
original CLI or a fixed User Id.
Sys Atd: the CLI configured for the System
Attendant through Web PGM 113 and 151.
Original CLI: the CLI received by the system for
the original incoming call.
Fixed Table: the SIP User ID from the SIP UID
Fixed Table Index attribute assigned below.
SYS ATD/
Original CLI/
Fixed Table
SYST ATD
From Display
The “Display” field of the “From” header can be
configured to use the below:
System Rule:
a. From ID = System Atd, display Contact
Display Name from PGM 126, otherwise display
Attendant Station Name from PGM 111 or blank.
b. From ID = Original CLI, display the Name in
received by the system for the original call.
c. From ID = Fixed Table display Contact
Display Name from PGM 126 or Station Name from
PGM 111 or blank.
Original CLI: the CLI received by the system for
the original incoming call.
SYS RULE/
Original CLI
SYS RULE
P-Asserted-ID
The ID in the “P-Asserted ID” header of SIP
messages can be based on the System Attendant,
the Original CLI or a fixed User ID.
SYS ATD/
Original CLI/
Fixed Table
SYST ATD
