iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
453
Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Sys Atd: CLI: the CLI configured for the System
Attendant through Web PGM 113 and 151.
Original CLI: the CLI received by the system for
the original incoming call.
Fixed Table: the SIP User Id from the SIP UID
Fixed Table Index attribute assigned below.
P-Asserted-ID Display
The “Display” field of the “P-Asserted Id” header
can be configured to use the below:
System Rule:
a. P-Asserted ID = System Atd, display
Contact Display Name from PGM 126, otherwise
display Attendant Station Name from PGM 111 or
blank.
b. P-Asserted ID = Original CLI, display the
Name in received by the system for the original call.
c. P-Asserted ID = Fixed Table display
Contact Display Name from PGM 126 or Station
Name from PGM 111 or blank.
Original CLI: the CLI received by the system for
the original incoming call.
SYS RULE/
Original CLI
SYS RULE
Remote-Party-ID
The Id in the “Remote-Party ID” header of SIP
messages can be based on the System Attendant,
the Original CLI or a fixed User ID.
Sys Atd: the CLI configured for the System
Attendant through Web PGM 113 and 151.
Original CLI: the CLI received by the system for
the original incoming call.
Fixed Table: the SIP User ID from the SIP UID
Fixed Table Index attribute assigned below.
SYS ATD/
Original CLI/
Fixed Table
Original CLI
Diversion
The Id in the “Diversion” header of SIP messages
can be based on the System Attendant, the Original
CLI or a fixed User ID, or Unused.
Unused: no Diversion header provided.
Sys Atd: the CLI configured for the System.
Attendant through Web PGM 113 and 151.
Original CLI: the CLI received by the system for
the original incoming call.
Fixed Table: the SIP User ID from the SIP UID
Fixed Table Index attribute assigned below.
Unused/
SYS ATD/
Original CLI/
Fixed Table
Unused
Offnet Call Forward by Station
The below apply to calls routed from a CO/IP Line to an Off-net location by a station over a SIP Trunk.
From/Contact ID
The Id in the “From” and “Contact” headers of SIP
messages employ the forwarding Station, the
original CLI or a fixed User ID.
Extension: the Extension SIP User ID or
Extension Outgoing CLI as assigned for the From
ID under ID Individuality.
Original CLI: the CLI received by the system for
the original incoming call.
Extension/
Original CLI/
Fixed Table
Extension
