Table 4.4.8.3-1 SIP CO ATTRIBUTES
ATTRIBUTE DESCRIPTION RANGE DEFAULT
Display Name from PGM 126, otherwise display
Station Name from PGM 111 or blank.
b. P-Asserted = Original CLI, display Station
Name from PGM 111 for ICM call or the Name in
received by the system for the original outside call.
c. P-Asserted = Fixed Table display Contact
Display Name from PGM 126 or blank.
Original CLI: the CLI received by the system for
the original incoming call.
Remote-Party-ID
The Id in the “Remote Party Id” header of SIP
messages employ the Station CLI, the original CLI
or a fixed User ID.
Extension: the Extension SIP User ID or
Extension Outgoing CLII as assigned for the From
ID under ID Individuality.
Original CLI: the CLI received by the system for
the original incoming call or station number for ICM
call.
Fixed Table: the SIP User ID from the SIP UID
Fixed Table Index attribute assigned below.
Extension/
Original CLI/
Fixed Table
Extension
Diversion
The Id in the “Diversion” header of SIP messages
can be based on the calling station, the Original CLI
or a fixed User ID, or Unused.
Unused: no Diversion header provided.
Extension: the Extension SIP User ID or
Extension Outgoing CLII as assigned for the From
ID under ID Individuality.
Original CLI: the CLI received by the system for
the original incoming call or the station number for
ICM call.
Fixed Table: the SIP User Id from the SIP UID
Fixed Table Index attribute assigned below.
Unused/
SYS ATD/
Original CLI/
Fixed Table
Unused
SIP UID Assignment
SIP User ID Fixed Table
Index
When a header is assigned to use “Fixed Table”,
the ID from this SIP User ID (PGM 126) Table index
is used.
Index
SIP User ID SELECTION
When a header is assigned to use the “Extension
SIP-User-ID Table”, the SIP User ID is selected
using this SIP UID index in the Station Attributes
(PGM 111).
Index,
Index 2,
Index 3
SIP User Table
Index
External CODEC Priority Configuration
1
st
~5
th
priority
1st. priority
2nd. priority
3rd. priority
4th. priority
5th. Priority
1. If specify priority to a specific CODEC then it will
work for negotiation RTP data.
2. If only 1st. priority is specified and the others are
None/
g.711-u/
g.711-a/
g.723.1/
g.729/
g.729-a/
g.722
none
