iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
471
< Ericsson-LG Enterprise LIP8002 / LIP88xx/LIP-8XXXE >
− MPB/UCP proceed provisioning for LIP8002 / LIP88xx/LIP-8XXXE
< Other 3rd party SIP Extensions >
− Does not proceed provisioning
Private Mac
: specify MAC address if provisioning target is only for one specific SIP
extension / Optional
< For What ? >
Re-Registration Timer
: this will be useless if [SIP User ID Attributes (PGM 126) - Registration
Timer Usage] is ON
SIP Extension’s Local UDP/TCP/TLS Port number
Proxy Port
: Server port number in sight of SIP Extension toward MPB/UCP
Transport
: Signaling mode
SIP Extension’s CODEC Priority
NTP Server and DST setting
The default volume of Speaker/Handset/Headset, maximum volume of Handset
Table 4.4.8.8-1 SIP PHONE PROVISIONING
ATTRIBUTE DESCRIPTION RANGE DEFAULT
CONFTYPE
To modify or view a Configuration file, from the drop-down,
select an Ericsson-LG Enterprise SIP Phone type.
None
MAC address must just be entered for Private Conf file
Private MAC
There are two types of Config files, a global file for all phones of
a specific type and a phone specific file. To view or modify a
Phone specific file, enter the MAC address of the SIP phone.
Private MAC
address
Don’t enter MAC address for common Conf file
Registration Timer
When the SIP User ID Attributes are configured with
Registration Mode=Register and the Registration Timer
Usage=OFF, this timer is used to determine the valid
registration period.
120-3600 3600
Local UDP Port
When employing UDP transport, this port number is employed
for messages from the SIP phone.
Port (1-65535) 5060
Local TCP Port
When employing TCP transport, this port number is employed
for messages from the SIP phone.
Port (1-65535) 5060
Local TLS Port
When employing TLS transport, this port number is employed
for messages from the SIP phone.
Port (1-65535) 5061
Local RTP Port
The system sends RTP packets to the SIP phone using the first
port available starting with this port number.
Port (1-65535) 23000
Proxy TCP Port
The SIP phone will send messages to the UCP system over this
SIP Server port.
Port (1-65535) 5060
Proxy TLS Port
The SIP phone will send messages to the UCP system over this
SIP Server port.
Port (1-65535) 5061
Transport Mode
The IP packet transport mode used between the system and
SIP phone for signaling messages is defined as UDP, TCP or
TLS. In case of TLS, the options configured in the SIP Common
UPD
TCP
TLS
UDP
