iPECS UCP - Page 532

iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
517
Table 4.4.10.6-1 NETWORK NUMBERING PLAN TABLE
ATTRIBUTE DESCRIPTION RANGE DEFAULT
number. UCP: 20000~31999
MPB IP Address
This field is the IP Address of the destination system for
the code
0.0.0.0
MPB Port number
The TCP/IP port number of destination system for the
Net Numbering Plan code is defined.
0000-9999 5588
Digit Repeat
When the number plan code, see above, is for PSTN call
or transit-call, the number code can be included in
SETUP message.
Yes
No
No
PSTN Enblock
When a PSTN receives a Transit-out call from a
networked user, the digits can be sent En-block (YES) or
Over-lap (NO).
Yes
No
No
PSTN CLI Method
The CLI sent with the call for this code can be set as the
NET CLI (station number) or PSTN, which sends the CLI
configured for the CO/IP Line and Station CLI.
NET
PSTN
NET
CO Attendant Code
CLI
When a networked system places a transit out call, the
Centralized ATD CLI can be sent.
OFF
ON
OFF
Firewall Routing
When the system can communicate with the networked
system directly, over a common VPN, the systems Non
Firewall address is sent in IP packets (OFF). Otherwise,
the Firewall IP address is sent (ON).
OFF
ON
ON
Transit Out Auth
COS
When a user requests a transit-out call by seizing a CO
line, COS may be applied according to the authorization
code.
Yes
No
No
SMDR Digit Hide
For a Transit-out call from the iPECS, the networked
system that places the call may desire to receive the
Authorization code
Yes
No
No
Site name
A twelve-character name can be assigned to the system
for use with network calls.
Max. 12 characters
Emergency reroute
timer
When a networked station places an Emergency call and
the “Emergency CO or Group” in the Station Common
Attributes is a Transit-out CO/IP Line or group, the call
will Fail-over to the “Fail-over CO Group” in PGM 133 or
the “Net Reroute CO Group” in PGM 321 after this timer
expires. The “Fail-over CO Group” will have priority.
0-10
(Sec.)
00
Tunneled SIG MSG
Send and Receive H323 message that include ISDN
QSIG message. It is used to make networking with
Panasonic system.
OFF
ON
OFF
Alternate/Secondary
signal port
This destination signal port is used on calling to remote
network system. A default destination signal port is TCP
1720 but the port number is changed if this field is
configured to valid value. When the system is installed
behind xDSL modem, the problem of consecutive second
call can happen by uncontrolled H.323 ALG function at
xDSL modem. This field can be used to solve the
problem of consecutive second call. Here, the value
should be an alternate or secondary receiving signal port
which is configured at remote system.
0-65535
Local route ID These two fields are used when a remote network Max. 15 characters
