iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
135
Table 3.3.6.20-1 SYSTEM TIMERS I (PGM 180)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
14
CALL RESTRICT TMR(min)
CHECK PGM 123-F2
Not used. Check PGM123-BTN2 00~99
(minutes)
00
15
CO DIAL DLY TMR(100ms)
(00-99) : 05
Delay for through connection to
prevent illegal dialing when CO/PBX
has slow response.
00~99
(100msec)
05
16
RLS GUARD TMR(100ms)
(010-150) : 020
When a CO Line is returned to idle,
the system will deny access for this
time to assure the PSTN returns the
CO circuitry to idle.
010~150
(100msec)
020
17
CO RING OFF TMR(100ms)
(010-150) : 060
This timer sets the maximum ‘OFF’
duration of the incoming ring cycle to
determine when a call has been
abandoned.
010~150
(100msec)
060
18
CO RING ON TMR(100ms)
(1-9) : 2
This timer sets the ‘ON’ time of the
incoming ring cycle for the Ring
Detect circuitry of the system to
recognize an incoming call.
1~9
(100msec.)
2
19
ELAPSED CALL TMR(sec)
(005-900) : 180
Users can receive a periodic tone
indicating the length of an outgoing
call. This timer sets the time before
and between the tones. Note Call
Time Tone must be enabled in PGM
112-button 1.
005~900
(seconds)
180
20
WEB PWD GUARD TMR (min)
(001-999) : 005
If no data packets are received during
a Web Admin connection for the
Guard time, a password check will be
initiated by the system.
001~999
(minutes)
5
21
ON HOOK IDLE TMR (sec)
(00-99) : 00
Phone (IP/DKTU) goes to idle after
this timer when the phone receives
disconnect message or signal from
CO line.
00~99
(seconds)
0
22
CALL REC REPEAT TMR(sec)
(000-999) : 000
If record warning tone is set and this
timer is set greater than 1, it works
periodically when it’s recorded.
000~999
(seconds)
0
Table 3.3.6.20-2 SYSTEM TIMERS II (PGM 181)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
1
FWD NO ANS TMR(sec)
(000-600) : 015
When a user activates No-Answer
Forward, calls will ring for this
duration before the calls are forward.
The Station No-Answer Forward timer
PGM 123 will take precedence.
000~600
(seconds)
015
2
DID/DISA NO ANS(sec)
(000-255) : 000
A DID/DISA call to a station will
forward to the DID/DISA Destination
assigned in PGM 167 should this
timer expire before the call is
answered.
000~255
(seconds)
000
