Table 4.4.4.1-1 Common Attributes
ATTRIBUTE DESCRIPTION RANGE DEFAULT
assigned, this timer defines the allowed call duration. 00 = disable
DISA Delay Timer
Once answered, the system attaches a DTMF receiver to
the DISA call to receive caller-dialed digits. This timer
introduces a delay before attaching the DTMF receiver to
the CO line. (Intended for Russia only)
0-9 seconds 0
DISA Answer Timer
When a call is received on a CO line with DISA service,
the system will answer the call when the DISA Answer
Timer expires. (Intended for Russia only)
0-9 seconds 0
Tone Attributes
CO Line MOH
A held call can be connected to one (1) of ten (10)
possible audio sources while on Hold as Music-on-Hold
(MOH).
Refer to Sys
Hold/
Internal Music/
External Music/
VSF MOH/
SLT MOH1~5/
VSF MOH2~3
Refer to Sys
Hold
CO Dial Tone
ISDN Lines may provide a digital signal rather than actual
tones. In this case, the iPECS can provide the tones. If
the ISDN provides the tone, the Tone is “ON”, for an
iPECS system-generated tone, the tone is set to “OFF”.
OFF
ON
ON
CO Ring Back Tone
OFF
ON
OFF
CO Error Tone
OFF
ON
OFF
CO Busy Tone
OFF
ON
OFF
CO Line Dial Tone
Source
One of eleven sources can be defined as dial tone for use
by the CO line.
Dial Tone/
Internal Music/
External Music/
VSF MOH/
SLT MOH1~5/
VSF MOH2~3
Dial Tone
CO Ring Back Tone
Source
One of eleven sources can be defined as ring back tone
for use by the CO line.
Ring Back Tone/
Internal Music/
External Music/
VSF MOH/
SLT MOH1~5/
VSF MOH2~3
Ring Back
Tone
COL Ring Tone
One of sixteen Ring Tones can be configure for use by
this CO Line.
00-16 0
