Table 3.3.3.2-3 STATION ATTRIBUTES III (PGM 113)
BTN ATTRIBUTE/DISPLAY DESCRIPTION RANGE DEFAULT
9
100-110 CALL WAIT
(0-3) : For Ext/Int
When a busy station receives a call,
the call may queue to the station
instead of receiving busy tone. With
Call Wait, the caller will hear Ring-
back and the user sees the CO line
LED flash.
If this option is set to a station, and a
co-line is ring assigned to the
station, second ring assigned call
CLI will show in the station’s LCD.
0: OFF,
1: For
External/Internal
2:For External,
3: For Internal
For
External/Internal
10
100-110 LEFT MSG EXEC
(1:ON/0:OFF ) : ON
When a call is forward to the
Secretary of an Executive/Secretary
pair, messages can be left for the
Executive (ON) or Secretary (OFF).
0: OFF
1: ON
ON
11
100-110 E&MIC HEADSET
(1:ON/0:OFF ) : OFF
Select E&MIC Headset mode. 0: OFF
1: ON
OFF
12
100-110 ENBLOCK MODE
(1:ON/0:OFF ) : OFF
When On, the user-dialed digits are
stored at iPECS IP or LDP Phones
until explicitly sent by the user.
When sent, all dialed digits are sent
to the system in a block. En-block
mode is only available to iPECS IP
and LDP Phones with 3-Soft keys.
0: OFF
1: ON
OFF
13
100-110 MSG RETRIEVE
(1:FIFO/0:LIFO ) : LIFO
Messages stored in the VSF may be
retrieved in either a FIFO (first-in-
first-out) or LIFO (last-in-first-out)
order based on this entry.
1: FIFO
0: LIFO
LIFO
14
100-110 VMID NUMBER
100
When using an adjunct VM, the
system can translate the Mailbox
number from the user’s station
number to the assigned VMID. The
system sends the station number or
VMID to the VM (in-band or SMDI) in
order to identify the appropriate
Voice Mailbox.
0000-9999 Station #
15
100-110 AUTO ACD-DND
([SPD],0-9,*,#): ..
If an Agent does not answer an ACD
call in the ACD No Answer timer, the
Agent enters an Unavailable state
with the Reason code entered here.
The reason code is sent in the ACD
Event message.
0: None
#, *
1 ~ 9
None
16
100-110 FWD IF OOS
(1:ON/0:OFF) : OFF
If a station is Out-of-Service and has
previously forwarded calls, the
system will forward the calls, if
enabled here.
0: OFF
1: ON
OFF
17
100-110 BACK LIGHT
(O:OFF/1:BUSY/2:ON): 1
The backlight of the LIP phones is
assigned to stay off, light only when
the station is busy, or light
constantly.
0: OFF
1: Busy
2: ON
Busy
