Table C-3 STATION DATA
BTN SUB-MENU RANGE DEFAULT REMARK
PGM: 124 - Linked Pair Station Attributes
1 Set IP Address xxx.xxx.xxx.xxx
2 Router IP Address xxx.xxx.xxx.xxx
3 Set Mac Address xx:xx:xx:xx:xx:xx
PGM: 125 - ICM Tenant Group
1 Group Attendant Station No.
2 Group Access Group 01~15 Group 01
PGM: 127 – Station VM Attributes
1 VM COS 1-5 1
2 Administrator Mail Box EN/DIS DISABLE
3 Announce Only Mail Box EN/DIS DISABLE
4 Announce Only Option
Previous Menu
Hang Up
Previous
Menu
5 Company Directory – First Name
6 Company Directory – Last Name
7 Cascade Mail Box
8 Cascade Type 1: ON, 0: OFF OFF
9
Message Rewind/Fast Forward
Time
3-99(SEC) 4
10 Notify Retry count 00-99 3
11 Notify Dial time 00-99 5
PGM: 128 – Station CCR Table
1-10
Station CCR 1-14
11
CCR table usage 1: ON, 0: OFF OFF
12
CCR One Digit 1: ON, 0: OFF OFF
13
* Button Used As 0-3 0
14
# Button Used As 0-3 0
PGM: 129 - DSS Label Edit
LSS Label LSS index + button … Max 16 char.
Table C-4 BOARD DATA
BTN SUB-MENU RANGE DEFAULT REMARK
PGM: 130 - H.323 VoIP Attributes
1 H.323 Setup Mode 0~1 Fast 0: Fast/1: Normal
2 H.323 Tunneling Mode 1: ON, 0: OFF ON 0:Off/1:On
3 H.323 DTMF Path 0~1
0: In-band
1:Out/0:In
4 H.323 DiffServ Pre tagging 00~63 4
5 RAS Usage 1: ON, 0: OFF OFF
6 RAS Multi-cast IP Address IP address 224.0.1.41
7 RAS Multi-cast IP port Port number 1718
8 RAS Uni-cast IP Address IP address 82.134.80.2
9 RAS Uni-cast IP port Port number 1719
10 RAS Keep-alive Timer 001 ~ 999 120 1 second increments
11 RAS Numbering Plan prefix 24 digits
12 RAS Gateway Id 128 characters Web Admin only
