Table C-4 BOARD DATA
BTN SUB-MENU RANGE DEFAULT REMARK
13 RAS Light RRQ 1: ON, 0: OFF OFF
14 TCP Keep Alive 1: ON, 0: OFF ON
15 FAIL OVER USAGE 1: ON, 0: OFF OFF
16 Fail over Time 03-10 (Sec.) 5
17 Fail over Group 01-21
18 Q931 START PORT 00001-65535 2048
19 Q931 END PORT 00001-65535 2559
20 H245 START PORT 00001-65535 2560
21 H245 END PORT 00001-65535 3071
22 RAS START PORT 00001-65535 2048
23 RAS END PORT 00001-65535 3071
24 H.323 VoIP Attributes
24-1 MEDIA START PORT 00001-65535 6000
24-2 MEDIA END PORT 00001-65535 7036
24-3 DATA START PORT 00001-65535 8500
24-4 DATA END PORT 00001-65535 8548
PGM: 131 -T1/E1/PRI Attributes
1 T1 Setup Mode 0~1 D4 0:D4/1:ESF
2 T1 Line Mode 0~1 B8ZS 0: B8ZS/1:AMI
3 PRI Line Mode 0~1 TE 0:NT/1:TE
4 PRI/E1 CRC Check 1: ON, 0: OFF OFF
5 E1 R2 DSP Check 1: ON, 0: OFF OFF
6 DCO PX Type
1: S1240
2: TDX1B
3: STANDARD
4: CONGES_DIS
STANDARD
PGM: 132 - Board Base Attributes
1 Router IP address IP Address
2 Device CODEC Type 0-4 4
0: G.711,
1: G.723.1,
2: G.729,
3: G.722
4: System Codec refer to
PGM 161-button 9.
3 Firewall IP address IP Address
4 RTP Security 1: ON, 0: OFF ON
5 TNET Enable 1: ON, 0: OFF OFF
6 UMS Sender e-mail address 40 Characters Web only to modify
7 T38 Enable 1: ON, 0: OFF OFF
8 USE Board IP for SIP 1: ON, 0: OFF OFF
9 RTP firewall IP IP address
10 T38 Port Usage
0: DIFF WITH
VOICE
1: SAME AS
VOICE
2: TRIGGERING
0
11 RFC2833 Payload 000-127 0
12 RFC2833 Volume 00-36 0 -dB
