iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
641
Table C-4 BOARD DATA
BTN SUB-MENU RANGE DEFAULT REMARK
13 RFC2833 Redundancy 1-8 0
Table C-5 CO LINE DATA
BTN SUB-MENU RANGE DEFAULT REMARK
PGM: 140 - CO Service Attributes
CO Service Type Flex 1~4 1 (Normal)
1: Normal CO line, 2: DID,
3: TIE Line, 4: Unused
PGM: 141 - CO/IP Line Attributes I
1 CO/IP Group Assignment 01-20
2 CO Line COS 1~5 1
3 CO Start Signal 1: Ground, 0: Loop Loop
4 CO Line Type 1: PBX, 0: CO CO
5 CO Line Signal Type 1: DTMF, 0: Pulse DTMF
6 Flash Type 1: Ground, 0: Loop Loop
7 Universal Night Answer 1: ON, 0: OFF OFF
8 CO/IP Group Auth 1: ON, 0: OFF OFF
9 Data Station No 4 digits
FAX/Modem can be assigned
to STA
10 Tenancy Group 00~ 15 00
11 CO VoIP Mode 1 ~ 6 Common
1: Common, 2: H.323 only, 3:
SIP only, 4: RTP RLY, 5:
H.323/TRP RLY, 6: SIP/RTP
RLY
12 PROCTOR ON/OFF 1: ON, 0: OFF OFF
13 WAIT IF VSF BUSY 1: ON, 0: OFF ON
14 Unused
15 Unused
16 COL RING TONE 1-12 0 0 is Not Available
17 Unused
18 Gain table index 1-3 1
19 Tone table index 1-5 1
20 Digit conversion table index 01-15 01
PGM: 142 - CO/IP Line Attributes II
1 CO Line Name Display 1: ON, 0: OFF OFF
2 CO Line Name Assign 12 characters - Max 12 character, alpha entry
3 Metering Unit 0~6 0
4 Line Drop using CPT 1: ON, 0: OFF OFF Not Supported
5 DISA Authorization Code 1: ON, 0: OFF ON
6 CO Line MOH 0~10 1
0: Refer to System hold, 1:
INT Music, 2: EXT music, 3:
VSF MOH, 4~8: SLT
MOH1~5, 9~10: VSF MOH2~3
7 CO Dial Tone 1: ON, 0: OFF ON
8 CO Ring Back Tone 1: ON, 0: OFF OFF
9 CO Error Tone 1: ON, 0: OFF OFF
10 CO Busy Tone 1: ON, 0: OFF OFF
11 DISA CO Access 1: ON, 0: OFF OFF
