iPECS eMG80 & eMG800 & UCP
Administration and Programming Manual Issue 1.6
81
Table 3.3.5.2-3 CO/IP ATTRIBUTES III (PGM 143)
BTN ATTRIBUTE/DISPLAY DESCRIPTION DEFAULT
2
01-02 CLIP TABLE IDX
INDEX : NOT ASSIGNED
When a call is placed on an ISDN Line, the
system will send caller id using the number
from the CLIP/COLP Table –PGM 201- entry
defined by this parameter. For entry 00, the
CLI STA NO entered in PGM 114-button 6 will
be used in place of the station number. For
other entries, the station number is added as
a suffix to the entry in PGM 201.
None
3
01-02 ENBLOCK SENDING
(1:ON/0:OFF) : OFF
This entry determines if the system sends
dialed digits to the ISDN line as they are
received (Overlap) or collects all digits and
forwards them in a block, ENBLOCK.
eMG80 : OFF,
eMG800: ON
4
01-02 TYPE OF NO(0-4)
NATIONAL (2)
For outgoing calls on the ISDN Line, this
parameter defines the “Type of Number Plan”
provided in Calling Party Information Element
of the ISDN call SETUP message.
0: UNKNOWN
1: INTERNATIONAL
2: NATIONAL
3: Unused
4: SUBSCRIBER
2
5
01-02 DID REMOVE NO
(00-99) : 00
When a DID call is received on an ISDN Line,
this entry determines the number of digits that
will be removed starting with the first received
digit.
00
6
02 TEI TYPE
(1:AUTO/0:FIX) : AUTO
The TEI (Terminal Endpoint Identifier) is a
unique identifier for each device attached to
the ISDN line. When the system shares an
ISDN connection with other devices, the TEI
should be automatic to assure no conflict with
other attached devices.
When the ISDN connection is not shared, the
Fixed identifier option should be employed.
AUTO
7
02 ISDN-SS CD/CR
(1:EN/0:DIS) : DISABLE
Permits a user access to ISDN
Supplementary Call Deflection or Call Re-
route Service.
(Except USA version)
Disable
8
02 ISDN 1 DGT RM
(1:ON/0:OFF) : OFF
Select one digit remove mode in ISDN Called
Digits (for Italy).
OFF
9
001-002 AOC TYPE (0-5)
NO SERVICE (0)
When assigned, the system will analyze the
Advice of Charge information in the Facility
Message according to the ETSI specifications
with appropriate regional protocol support.
No Service
10
001-002 ISDN LINE TYPE
(1:U/0:A): U_LAW
The system will encode voice using the A-law
or u-law PCM format and should be set to
match the ISDN Back bone type.
u-Law
11
01-02 CALLING SUBADDR
(1:ON/0:OFF) : OFF
For outgoing calls, the user’s station number
may be included in the ISDN call SETUP
message Sub-address field.
OFF
