Screen Editing
3.6 Parts
Parts Types and Limitation
The parts listed below can be placed on the screen.
Types of Parts
Parts Type Remarks
Overlap Normal Overlap SP SP: single part
Call-overlap I I: Item which does not have an area
Multi-overlap I
Switch SP
Lamp SP
Data Display Numerical Data Display SP
Character Display SP
Message Display SP
Table Data Display SP
Message Message MP MP: combined parts
Comment Display MP
Entry MP
Graph Bar Graph SP
Pie Graph SP
Closed Area Graph SP
Panel Meter SP
Statistic Bar Graph SP
Statistic Pie Graph SP
Trend Trend Graph SP
Trend Sampling MP
Data Sampling MP
Alarm Alarm Tracking MP
Bit Order Alarming MP
Alarm Sub Display MP
Time Order Alarming MP
Alarm Logging MP
Graphic Graphic MP
Graphic Relay MP
Macro Macro I
Interval Timer I
Calendar Time Display I
Calendar SP
Recipe MP
Multimedia Animation MP
Video MP
JPEG Display MP
Sound I
Network camera display MP
Remote desktop display MP
