4.3 Drawing Methods
4-14
Parallelogram
1. Click the “ ” mark on the right of the [Frame Type] icon on the toolbar.
Select the desired frame type from the list displayed. ([With Frame (Paint)] is selected as an
example.)
2. Select a frame color from the [Line Color/Frame Color] icon and a color of the frame inside from
the [Paint Color] icon.
3. Click the “ ” mark on the right of the [Box] icon on the toolbar.
Click [Parallelogram] from the pull-down menu.
The [Parallelogram] icon is depressed and the mouse cursor is turned into a cross-shaped cursor.
4. Drag the mouse from the start point to the end point of the upper side.
Start point End point
Drag.
To Next Page
