3.6 Parts
3-51
3
Screen Editing
From the [Parts] Menu
Placement procedure (e.g. switch)
1. Click [Switch] from the [Parts] menu.
Move the mouse to the editing window. The part is displayed with the cursor.
* The part displayed here is the default or the one which was changed or selected last.
2. Click the mouse in an arbitrary position on the screen. The switch part selected in step 1. is placed
on the screen.
To hide the parts list behind the editing window, uncheck the [Always Display on Top] in the [View]
menu of the [Parts List] window.
The part is displayed with the
cursor moved.
Click. The switch part is placed.
