2.2 Menu Bar
2-8
[Registration Item] Menu
For more information on the [Registration Item] menu, refer to “5 Registration Items” (page 5-1).
[Screen Setting] Menu
This menu is available during screen editing, and the settings are only valid for the screen currently
opened.
[System Setting] Menu
This menu is used when you make settings of, such as, the edit model, devices to be connected, and
fonts.
For more information, refer to “Chapter 1 System Setting” in the V8 Series Reference Manual.
Screen Setting Allows you to select the screen background color, item select memory, etc.
For more information, refer to page 2-39.
OPEN Macro Edit Allows you to edit the macro executed when the screen is opened.
CLOSE Macro Edit Allows you to edit the macro executed when the screen is closed.
CYCLE Macro Edit Allows you to edit the macro executed while the screen is opened.
Local Function Switch
Setting
Allows you to set function switches activated while the screen is opened.
For a switch commonly used for all screens, go to the [Global Function
Switch Setting] dialog selected from the [System Setting] menu.
Edit Model Selection Allows you to select an edit model of the V8 series.
Device Connection
Setting
Allows you to select controller models connected to MONITOUCH.
Device Memory Map Allows you to perform batch data transfer or sampling between controllers.
Ethernet
Communication
Allows you to set the network table associated with the use of the IP
address of a local port (V8 series) or the macro command EREAD or
EWRITE.
Unit Setting Allows you to make settings associated with MONITOUCH, such as the
backlight and the buzzer.
Font Setting Allows you to set interface languages displayed on MONITOUCH.
Global Function
Switch Setting
Allows you to set function switches that are commonly used on all screens
displayed on MONITOUCH.
For setting function switches enabled while a certain screen is opened, go
to [Local Function Switch Setting] dialog selected from the [Screen Setting]
menu.
CF Card Setting Allows you to specify a location of where to connect the CF card and a
access folder name.
Attribute Setting Allows you to set a format, in which writing to a CSV file takes place in
recipe mode.
Buffering Area Setting Allows you to make buffering area settings associated with the use of the
sampling function.
Memory Card Setting Allows you to make settings for the memory card mode (the settings are
made automatically when the sampling function is used).
Macro Setting Allows you to make settings for initial, global, or event timer macro.
