3.7 Parts Placement and Setting
3-89
3
Screen Editing
Macro / Interval Timer
Placement procedure
1. Click the item selected from [Parts] → [Macro], or drag it from the parts list or Catalog View.
Move the mouse to the editing window. The icon is displayed along with the cursor.
2. Click the mouse in an arbitrary position on the screen. The icon is placed.
Setting method
Click (or double-clicking) on the placed icon brings up the item dialog.
The icon is displayed by moving the mouse.
Click. The icon is placed.
To Next Page
