Parts Editing
A3-26
Calendar
One calendar part is capable of containing the entire calendar information (year, month, day, hour,
minutes, seconds, and the day of the week). Meanwhile, the calendar information can be divided into
components. These components can be registered one by one.
Structure
A calendar part has a structure consisting of several components. These components can be
individually moved and enlarged during editing.
02 - 06 - 15 17 - 20 - 15 Sunday
6 / 20
Sunday
17 : 20
These are also independent
calendar parts.
One calendar part
YY DD hh ss
MM
mm
SUN
Graphic data
Frame (part area)
Part basic area
Freely movable
You can select components of a calendar part in the [Calendar] dialog. The calendar part will
contain the components checked in the dialog.
For more information on the features of calendar part, refer to the V8 Series Reference Manual.
Check or uncheck
the boxes to show or
hide the data items.
To Next Page
