5.9 Data Block
5-35
5
Registration
5.9 Data Block
Data blocks (parts) are provided as areas where data displays such as numerical data or character
display parts or graphics are registered.
Data Block Structure
A maximum of 1,024 data blocks can be registered.
Calling a Data Block
Select [Data Block] from the [Registration Item] menu.
The [Data Block] dialog is displayed. Specify the data block number to be opened and click [OK].
(Alternatively, you can call the screen from the [Screen] menu in Project View.)
