2.2 Menu Bar
2-3
2
Editor
[File] Menu
New Opens a new file, and brings up the screen for editing.
Open Opens an existing screen data file.
A screen data file for the V7, V6, or GD-80 series can be opened and
converted into a file for the V8 series.
For more information, refer to the File Conversion Manual.
Save Saves the current file. (If it is a new file, you must give a name to the
file.)
Save As Saves the current file under a new or different name.
Property Allows you to check the information on the current file and to set up
the editing environment. For more information, refer to page 2-4.
Project Becomes active when Fuji Electric’s MICREX-SX is designated as
PLC1 in the [Device Connection Setting] dialog.
Transfer Transfers data between the computer and the V8 series or a memory
card.
For more information, refer to “6 Transfer with V8”.
Print Prints out the created screen data file from the printer connected to
the computer.
For more information, refer to “7 Print”.
Print Preview Allows you to preview the image to be printed.
Print Current Window Prints out the window currently opened.
Component Parts Editing Allows you to edit component parts.
CF Card Manager Allows you to write the V8 series data to a CF card or to convert the
data imported from the CF card to a specific file format. For more
information, refer to “Chapter 18 CF Card” in the V8 Series Reference
Manual.
Start Font Setting Selects a font type in language used for displaying text on the editor.
Start Emulator Launches Emulator or updates the emulator data when any changes
are made on the screen. For more information, refer to page 8-43.
Update Emulator Data
File Management Compares or copies data between different two files.
For more information, refer to page 8-78.
Quit Application Closes V-SFT Ver. 5.
