4.3 Drawing Methods
4-24
5. Select the drawing method.
Click [View] → [Toolbar] → [Drawing Method].
The [Drawing Method] toolbar is displayed.
6. Click the “ ” mark on the right of the [Arc/Sector] icon.
The pull-down menu is displayed.
Selects [Arc/Sector (On Arc)].
7. Drag the mouse from the start point to the end point.
8. When the mouse is released, the arc or sector is displayed.
9. Clicking the mouse to the desired position draws the arc or sector.
10. To reset the drawing setting, right-click or double-click the mouse.
By dragging the mouse again without resetting it, you can draw another arc or sector continuously.
Ellipse
1. Click the “ ” mark on the right of the [Frame Type] icon on the toolbar.
Select the desired frame type from the list displayed. ([With Frame (Paint)] is selected as an
example.)
: Start point
: End point
