3.4 Setting Menu
3-32
Memory Types
[PLC Memory]
This defines the memory of the connected PLC.
[Internal Memory]
This defines the memory address range to be set in the V8 series.
1. CPU No. This field becomes active when [Yokogawa: FA-M3], etc. is selected.
2. Port number This field becomes active when [1 : n] communication is selected.
$u (user memory)
For more details on the definition or range of the
internal memory, refer to “Appendix 6 Internal
Memory” in the V8 Series Reference Manual.
$L/$LD (user memory/non-volatile)
$T (user memory/per screen)
$M (user memory/per macro)
$MC (user memory/per macro)
$C (user memory/for component parts)
$s (system memory)
$P (system memory/8-way communication)
Ex.) Mitsubishi [A Series Link] (1 : 1)
Ex.) Yokogawa [FA-M3] (1 : 1)
Ex.) Mitsubishi [A Series Link] (1 : n)
1. CPU No.
2. Port number (Unit number to be set for SPU)
(Unit number to be set for SPU)
