It is possible to register user’s desired texts in the message editing area.
Texts for the bit order alarming, message mode, alarm logging or alarm tracking (parts) that will vary
according to the circumstances are registered in this area and can be displayed by the message
display function.
Message Structure
The message editing area is divided into 128 groups.
Each of which can contain 256 message lines. Therefore, you can register a maximum of 32768 lines.
The maximum permissible number of characters per line depends on the number of displayed dots
specified for MONITOUCH.
No. 0
No. 1
No.255
No. 0
No. 1
No.255
No. 0 AAAAAAAAAAAAA
No. 1 BBBBBBBBBBBBB
No.255 ZZZZZZZZZZZZZZ
No. 0
No. 1
No.255
Message
Group No. 0 Group No. 1 Group No. 2 Group No. 127
Message
Message
Message
Number of Displayed Dots Max. Number of Characters (1-byte)
800
× 600 100
640
× 480 80
